JHEMCU Ruibet F411 12A 1-2S AIO

¥ 7,300 税込

商品コード：

数量

1-2セルまで可能なオールインワンF4+12Aのワンボード！

4.4gと軽量でコンパクトな設計！



コントローラーはBeta Flight等で設定が可能！





Features:

Support ELRS, TBS,SBUS,IBUS,DSM2,DSMX Receiver

Support WS2812 etc. Programmable LED Strip

Support Buzzer

Onboard 12A 4in1 ESC

Con. Current: 12A

Firmware: BLheli_S Z_H_30_REV16_7.HEX

Input Voltage: 1-2S

Support PWM, Oneshot125, Oneshot42, Multishot, Dshot150, Dshot300, Dshot600



Specifications:

Brand: JHEMCU

Model: RuiBet F4

Item Name: 25.5x25.5mm F4 Flight Controller AIO 12A ESC

CPU: STM32F411

ICM: ICM42688

OSD: AT7456E

Barometer: NO

Blackbox: NO

USB Port: micro usb

BEC: 5V

UART: UART1, UART2

IIC: Support

Mouting Hole:25.5x25.5mm, M2

Weight: 4.4g



Package Contents:

1x RuiBet F4 AIO

2x 18AWG Cable

1x XT30 Connector

4x M2x6.5 Anti-vibration Ball

1x 10V 470UF Capacitor

1x 2P Cable
